Although they’re a staple of sci-fi movies and conspiracy theories, in real life, tiny flying microbots—weighed down by batteries and electronics—have struggled to get very far. But a new combination of circuits and lightweight solid-state batteries called a “flying batteries” topology could let these bots really take off, potentially powering microbots for hours from a system that weighs milligrams.
Microbots could be an important technology to find people buried in rubble or scout ahead in other dangerous situations. But they’re a difficult engineering challenge, says Patrick Mercier, an electrical and computer engineering professor at University of California San Diego. Mercier’s student Zixiao Lin described the new circuit last month at IEEE International Solid State Circuits Conference (ISSCC). “You have these really tiny robots, and you want them to last as long as possible in the field,” Mercier says. “The best way to do that is to use lithium-ion batteries, because they have the best energy density. But there’s this fundamental problem, where the actuators need much higher voltage than what the battery is capable of providing.”
A lithium cell can provide about 4 volts, but piezoelectric actuators for microbots need tens to hundreds of volts, explains Mercier. Researchers, including Mercier’s own group, have developed circuits such as boost converters to pump up the voltage. But because they need relatively large inductors or a bunch of capacitors, these add too much mass and volume, typically taking up about as much room as the battery itself.
A new kind of solid-state battery, developed at the French national electronics laboratory CEA-Leti, offered a potential solution. The batteries are a thin-film stack of material, including lithium cobalt oxide and lithium phosphorus oxynitride, made using semiconductor processing technology, and they can be diced up into tiny cells. A 0.33-cubic-millimeter, 0.8-milligram cell can store 20 microampere-hours of charge, or about 60 ampere-hours per liter. (Lithium-ion earbud batteries provide more than 100 A-h/L, but are about 1000 times as large.) A CEA-Leti spinoff based on the technology, Inject Power, in Grenoble, France, is gearing up to begin volume manufacturing in late 2026.
Stacking Batteries on the Fly
The solid-state battery’s ability to be diced up into tiny cells suggested that researchers could achieve high-voltages using a circuit that needs no capacitors or inductors. Instead, the circuit actively rearranges the connections among many tiny batteries moving them from parallel to serial and back again.
Imagine a microdrone that moves by flapping wings attached to a piezoelectric actuator. On its circuit board are a dozen or so of the solid-state microbatteries. Each battery is part of a circuit consisting of four transistors. These act as switches that can dynamically change the connection to that battery’s neighbor so that it is either parallel, so they share the same voltage, or serial, so their voltages are added.
At the start, all the batteries are in parallel, delivering a voltage that is nowhere near enough to trigger the actuator. The 2-mm2 IC the UCSD team built then begins opening and closing the transistor switches. This rearranges the connections between the cells so that first two cells are connected serially, then three, then four, and so on. In a few hundredths of a second, the batteries are all connected in series, and the voltage has piled so much charge onto the actuator that it snaps the microbot’s wings down. The IC then unwinds the process, making the batteries parallel again, one at a time.
The integrated circuit in the “flying battery” has a total area of 2 square millimeters.Patrick Mercier
Adiabatic Charging
Why not just connect every battery in series at once instead of going through this ramping up and down scheme? In a word, efficiency.
As long as the battery serialization and parallelization is done at a low-enough frequency, the system is charging adiabatically. That is, its power losses are minimized.
But it’s what happens after the actuator triggers “where the real magic comes in,” says Mercier. The piezoelectric actuator in the circuit acts like a capacitor, storing energy. “Just like you have regenerative breaking in a car, we can recover some of the energy that we stored in this actuator.” As each battery is unstacked, the remaining energy storage system has a lower voltage than the actuator, so some charge flows back into the batteries.
The UCSD team actually tested two varieties of solid-state microbatteries—1.5-volt ceramic version from Tokyo-based TDK (CeraCharge 1704-SSB) and a 4-volt custom design from CEA-Leti. With 1.6 grams of TDK cells, the circuit reached 56.1 volts and delivered a power density of 79 milliwatts per gram, but with 0.014 grams of the custom storage, it maxed out at 68 volts, and demonstrated a power density of 4,500 mW/g.
Mercier plans to test the system with robotics partners while his team and CEA-Leti work to improved the flying batteries system’s packaging, miniaturization, and other properties. One important characteristic that needs work is the internal resistance of the microbatteries. “The challenge there is that the more you stack, the higher the series resistance is, and therefore the lower the frequency we can operate the system,” he says.
Nevertheless, Mercier seems bullish on flying batteries’ chances of keeping microbots aloft. “Adiabatic charging with charge recovery and no passives: Those are two wins that help increase flight time.”
